Allison 4th Gen TCM Breakout Harness Adapter | J-47275-1

Allison 4th Gen TCM Breakout Harness Adapter | P/N J-47275-1

PRODUCT OVERVIEW
The Allison J-47275-1 is a 4th Gen TCM breakout harness adapter for Allison 4th Gen transmission controls. Application: Allison 4th Gen TCM diagnostics - 80-pin breakout box adapter (used with J-47279 harness).
Installed between the TCM and the vehicle harness, and used with the J-47279 harness, it gives technicians access to every TCM circuit to measure voltage, resistance and continuity while diagnosing shift, solenoid and sensor faults.

PART NUMBER IDENTITY
Primary Part Number: J-47275-1
Also listed as: J-47275 / ATT-47275
Product Type: 4th Gen TCM Breakout Harness Adapter
Brand / Manufacturer: Allison
Condition: New (unused)
Fits: Allison 4th Gen

APPLICATIONS AND FITMENT
Allison 4th Gen TCM diagnostics - 80-pin breakout box adapter (used with J-47279 harness) - diagnostic tool
Always confirm against the part number on your existing unit or your engine / machine serial number.

TECHNICAL SPECIFICATIONS
Catalogue description: Breakout harness (Kent-Moore J-47275)
Connector: 80-pin TCM breakout

USE
Workshop diagnostic adapter - no programming required.

INSTALLATION NOTES
Verify correct pin-to-pin mapping between vehicle harness and TCM connector — all signal pins (vehicle speed sensor, throttle position, brake signal, range selector, shift solenoid outputs) must be correctly routed through the adapter. Apply dielectric grease to connector faces. After installation, verify TCM communication using Allison DOC and confirm all input signals read correctly before conducting a driving test.

CONDITION AND WARRANTY
Condition: New (unused)
An unused unit. Packaging can vary by batch, and we can send photos of the actual unit before dispatch. Covered by our 365-day warranty and 30-day money-back guarantee.
Core / exchange: outright price - no core charge and no core return required.

BEFORE YOU ORDER
1. Compare the part number on your existing unit with J-47275-1 or a cross-reference listed above.
2. Send us a clear photo of your old part's label and your engine / machine serial number - we confirm the match before you buy.
3. Need more than one, or a quote for your fleet? Ask us for a bundle price.

FREQUENTLY ASKED QUESTIONS
Is the J-47275-1 new or used?
New (unused). An unused unit. Packaging can vary by batch, and we can send photos of the actual unit before dispatch.
What does the J-47275-1 fit?
Allison 4th Gen. Match your old unit's part number or send us your serial number to confirm.
Is there a core charge?
No. The price is outright - no core charge and no core return required.
How fast is shipping?
FREE worldwide express shipping (DHL / FedEx / EMS) with tracking, dispatched from Sharjah, UAE within 1–4 business days of cleared payment.
What if it is the wrong part?
You are covered by our 30-day money-back guarantee (unit returned unused and uninstalled) and a 365-day replacement warranty.
